Cool Top 120-e

Name: Cool Top 120-e
Brand: Webasto
SKU: cool-top-120-e

Jump to section

Air-conditioning system for electric vehicles

The Cool Top 120-e is a rooftop air-conditioning system designed for electric vehicles such as minibuses, light commercial vehicles and ambulances. Its 12 kW cooling capacity, variable compressor speed technology and compact design support reliable cabin comfort and low-noise operation. Whether for daily urban use or demanding field service, the Cool Top 120-e creates comfort for various types of electric commercial vehicles.

Benefits of Cool Top 120-e

Compact and lightweight design

Designed for small footprint and minimal weight —ideal where space and payload are limited.

Powerful cooling capacity

Delivers up to 12 kW of cooling capacity, enough to maintain a comfortable interior climate under high outdoor temperatures and full interior loads.

Modern refrigerant solution

Uses R1234yf refrigerant; Variable compressor speed technology supports optimized system operation.

Quiet operation

Compressor and blowers adapt their revolutions and output depending on cooling demand. This results in low noise levels after initial cool-down period.

Smart controls & integration

Includes electronic thermostatic regulation; optional CAN-bus / vehicle network interface for seamless integration; supports fresh air or recirculation modes.

Easy to install

Electrical compressor is already integrated into the A/C unit. System is already pre-charged with refrigerant. No need to install refrigerant lines within the vehicle.

Product details

Product specifications

Cooling capacity (nominal): 12kW
Refrigerant: R1234yf
Voltage: Compressors: 250 to 460 V DC; Electronics/blowers: 12 V
Maximum current: 7,5A @ 350V, 83A @ 13,5V
Max power consumption: High voltage ~2,625 W (compressor), Low voltage ~1,120 W
Airflow (evaporator blower): ~2,000 m³/h at 475 Pa
Fans: 2 condenser fans; 2 evaporator blowers, blower are brushless type
Dimensions (L × W × H): 1,605 × 1,290 × 300 mm
Weight: approx. 80 kg
Roof radius: 7,000 mm
Fresh air / recirculation: Included

Downloads

Cool Top 120-e - Datasheet

Get the complete catalog of air-conditioning solutions offered by Webasto.

Size: 266 KB
Format: application/pdf

Download

Air-conditioning solutions - Catalog
