BlueCool SX-Series

Name: BlueCool SX-Series
Brand: Webasto
SKU: bluecool-sx-series

Jump to section

Stand-alone air conditioning for up to five cabins

Webasto's BlueCool SX-Series standalone air conditioners are the perfect solution for vessels with up to five cabins. Each cabin is equipped with its own cooling unit. In the system, the compressor, condenser, evaporator and blower are pre-assembled on a stainless-steel condensate tray. The compressor is hermetically sealed. The compact systems are designed for 230 V and 115 V environments and cool at up to 27,000 BTU/h. They are extremely energy-efficient in consumption, very quiet and can also heat via a reverse function. It is operated via the innovative MyTouch display, and the evaporator temperature is displayed in real time.

Compact thermal module with integrated refrigerant and coolant circuits, heat-exchanger core and mounting for EV battery and powertrain thermal management.

BlueCool SX-Series S10

Compact refrigerant circuit module with evaporator/condenser coils, receiver-drier and routed refrigerant lines for Webasto vehicle thermal-management and HVAC systems.

BlueCool SX-Series S16

Compact refrigerant module with scroll compressor, condenser coil, receiver-drier and piping for vehicle heat-pump and thermal management systems.

BlueCool SX-Series S27

Benefits of BlueCool SX-Series

Optimized energy efficiency

The BlueCool SX-Series units impress with their low power consumption and ensure cost-efficient and environmentally friendly cooling.

Quiet, consistent operation

The appliances operate very quietly, and optional vibration absorbers and soft-start accessories increase comfort if required.

Universal Compatibility

The SX-Series devices can be used all year round (for cooling and heating) and worldwide, even in continuous operation under tropical conditions.

Product details

Product Specifications

Cooling capacity: 6,000 - 27,000 BTU/h (1.8 - 7.9 kW)
Integrated heating via reverse cycle
Rated voltage: 115 V or 230 V
Frequency: 50/60 Hz
Dimensions L x W x H (mm) / Weight (kg)

BlueCool SX-Series 230 V

SX6: 405 x 320 x 315 / 20.5

SX8: 405 x 320 x 315 / 23.5

SX10: 480 x 335 x 315 / 24

SX13: 510 x 350 x 370 / 28.2

SX16: 550 x 350 x 370 / 32

SX20: 590 x 340 x 370 / 36

SX27: 575 x 515 x 410 / 48

BlueCool SX-Series 115 V

SX6: 405 x 320 x 315 / 20.5

SX8: 405 x 320 x 315 / 23.5

SX10: 480 x 335 x 315 / 24

SX13: 510 x 350 x 370 / 28.2

SX16: 550 x 350 x 370 / 32

Model overview

SX6
SX8
SX10
SX13
SX16
SX20 (230 V only)
SX27 (230 V only)
