Power Test System
900 EX
The most advanced power test system: Dynamic. Accurate. Reliable.
The 900 EX is the most advanced high power test system for use in testing and emulating a wide variety of active and passive loads. Test faster and more efficiently with more predictive results. Bidirectional capability allows you to source and sink at the same time. The 900 EX is also regenerative, which will offset electricity costs.
The 900 EX is ideal for testing and emulating energy storage and drive train components of large electric and hybrid electric vehicles. The increased performance (rise time/slew rate) and increased accuracy make the 900 EX ideal for applications like EV (car, truck, bus), Industrial (ships, trains, trucks, and planes), Military (hybrid drives and aircraft launch systems), Power Electronics (Solar Panels, Inverters), and Hardware in the loop testing. Digital controls protect critical systems and components, and the system can self-adjust to external environmental events like unstable power sources. The bi-directional system can operate at ± 250kW, or combined, it can scale to ±1MW. The 900 EX, with LCD touchscreen display, is an intelligent system that will give you the accuracy, speed, and control to add value to your tests.
Supports standard EV tests including: FUDS, SFUDS, GSFUDS, DST, and ECE-15L.
Benefits of Power Test System 900 EX
This advanced system tackles a wide range of sources, loads, and battery storage systems. It streamlines the process by catching errors quickly, simulating real-world conditions for better predictions, and potentially saving you money through faster testing and regenerative energy use. Plus, its two channels juggle testing multiple devices at once, seamlessly integrates into your existing setup, and cools itself without needing extra equipment. Top it all off with various control modes, and you have got a versatile testing solution for all your DC needs.
Technical data Power Test System 900 EX
| Technical specifications | Independent | Parallel | Multi-unit |
| Voltage | 900 V | 900 V | 900 V |
| Current | 500 A | 1,000 A | 4,000 A |
| Power | 250 kW | 250 kW | 1,000 kW |
| Energy recovery efficiency | 93 % | ||
| Weight | 6,063 lbs. (2,750 kg) | ||
| Dimensions (L x W x H) | 72 x 39 x 76.5 in. (183 x 99 x 194 cm) | ||
Please find all technical specifications in the datasheet in the download section.
